Specifications

• Skin: Pre-painted aluminum sheet. (Thickness: 0.3-6.0mm)
• Surface Color: RAL9001.
• Core: PET (Polyethylene terephthalate) foam. (Density: 60-300kg/m³).
• Total Thickness: 10-30mm.
• Width: Max 2.6m.
• Length: Max 12m.

Inquiry

Product features

• Lightweight: Aluminium skin is generally less than 1 mm thick and the material itself is quite light, reducing the overall weight of the box truck and improving fuel efficiency and transportation efficiency.
• High Strength: The PET foam core provides good compressive and shear strength, and the sandwich structure composed of aluminum skins on both sides and the PET foam core in the middle endows the panel with high overall strength.
• Corrosion Resistance: The aluminum skin has good corrosion resistance, and the PET foam core is a closed-cell rigid foam that basically does not absorb water, which can effectively prevent the entry of moisture and chemicals, thereby enhancing the corrosion resistance of the panel.
• Good Insulation Performance: The PET foam core has low thermal conductivity, which can effectively reduce the heat exchange between the inside and outside of the box truck and maintain a relatively stable temperature inside the truck.
• Easy to Process and Install: The foam core panel is easy to cut, not only CNC, but also saws and blades can make it for individual users, which can be customized according to the actual needs of the box truck.
• Long Service Life: With good corrosion resistance, weather resistance and mechanical properties, aluminum skin PET foam panels can maintain good performance in long-term use and have a long service life.

Applications

• Truck floors.
• Truck walls.
• Truck roofs.
• Truck partitions.
• Truck doors.
