Specifications
- Thickness: 10-150mm
- Length: ≤12m.
- Width: ≤2.8m.
- Skin: CFRT (Continuous Fiber Reinforced Thermoplastic) sheet. (0.7-2.0mm)
- Core: EPP (Expanded Polypropylene) foam. (Density: 40kg/m³).
Description
Structural Diagram
The high-performance, lightweight composite panel is made by hot-pressing a continuous glass fiber reinforced PP surface layer (CFRT sheet) and an EPP (expanded polypropylene) foam core. This material combines the excellent cushioning properties of EPP with the high-strength surface characteristics of CFRT.
What is EPP Foam?
EPP (Expanded Polypropylene) foam is a high-performance polymer material. Made from polypropylene (PP) through physical foaming, it combines lightweight, high strength, heat and chemical resistance, and recyclability.
Continuous Fiberglass Reinforced PP Sheet
It is a high-strength thermoplastic composite sheet made of polypropylene (PP) as the matrix resin and continuous glass fibers as the reinforcement, produced through a continuous hot-pressing process. Unlike traditional short-fiber or fabric-reinforced materials, the continuous fibers are oriented and distributed in a specific direction within the sheet, providing greater strength, stiffness, and fatigue resistance.
Applications
CFRT skin EPP foam sandwich panels are widely used in various vehicle body structures:
- Refrigerated trucks: They serve as thermal insulation panels for the vehicle body, reducing vehicle weight and improving energy efficiency.
- Dry cargo trucks: They provide a strong, lightweight box structure, improving cargo loading efficiency.
- Recreational vehicles (RVs): They are used in wall and roof panels, balancing strength and comfort.
Get Your Custom Composite Panels
As one of the most dynamic fiberglass foam sandwich panel manufacturers in China, TOPOLOGROUP specializes in providing lightweight composite panel solutions. We produce a wide variety of foam-core composite panels to meet diverse application scenarios and functional requirements. With advanced production equipment, strict quality control and flexible customization capabilities, TOPOLOGROUP provides customers with reliable, durable and environmentally friendly composite panel solutions, making it your ideal composite panel partner.
