Specification
- Panel Thickness: 50mm. (30-250mm can be customized)
- Panel Width: 930mm, 950mm, 1000mm, 1130mm, 1150mm.
- Panel Length: Max 12m.
- Metal Sheet: 0.5mm PPGI/PPGL sheet.
- Surface Color: White, silver, black, blue, red and other RAL series.
- Surface Texture: Ripple, corrugated.
- Core material: Polyurethane (PUR/PIR) filled foam. (Density: 38-45kg/m³)
Description
Polyurethane insulation wall panels are a kind of building material with high-efficiency thermal insulation performance, and are commonly used in the fields of wall insulation, heat insulation and sound insulation in industrial and civil buildings.
Highlight Features
- Excellent thermal insulation performance.
- High strength and good compressive resistance.
- Good waterproof and moisture-proof performance.
- Significant sound insulation and noise reduction effect.
- Easy installation
Applications
- Factory buildings.
- Warehouses.
- Temporary shelters.
- Refrigerated trucks.
- Cold rooms, etc.
TOPOLOGROUP offers a wide range of high-quality insulated metal panels, available in various specifications to meet diverse industrial and commercial needs.
